7.3.3 ELECTRICAL CONNECTION
Open the electrical panel, introduce the supplying cable and the others according to the hole, connect them to the clamps and on
the disconnecting switch, close the panel.
The grounding connection is compulsory. The installer should connect the ground cable with the
suitable clamp situated within the electrical panel, with a yellow-green indication.
Make always reference to the wiring diagram.
No tension while wiring.
DEATH DANGER
Electrical connection, feed cables and protections should be realized according to the attached
wiring diagram and following local and international directions.
7.3.4 SUGGESTED PROTECTION
FRAME
1
2
3
4
MODELS
40
50
60
70
90
100
160
190
210
230
WITHOUT ELECTRICAL HEATERS
10 A
16 A
20 A
20 A
WITH ELECTRICAL HEATERS
20 A
32 A
40 A
50 A
TYPE
SINGLE-PHASE
THREE-PHASE
