CLAMPING BOX 6 POLES + PE
Clamps N - L - PE are for the supplying: connect the neutral on N, the phase on L and the PE on the opposite.
CLAMPING BOX 10 POLES
Clamps 101 - 102 are for the signal of alarms in the unit; it is possible to connect a light or to connect a board for the management
of the plant.
Clean contact, no supplying.
Clamps 103 - 104 are for the connection of a zone valv, a water valve or a water pump (max 1A) to manage the water supplying to
the unit. For equipment with consumption over 1A, interpose a contactor or a power-relai.
The drive is in 230V.
Clamps 105 - 106 are for the on/off at distance; connect a contact from a switch or from a board for the management of the unit
turning on at distance
Connect only a clean contact.
Clamps 107 - 108 are for the dehumidification on/off; connect a contact from a switch or from a board for the management of the
dehumidification at distance.
Connect only a clean contact.
Clamps 109 - 110 are for the heating on/off; connect a contact from a switch or from a board for the management of the
dehumidification at distance.
The contact functions only if the option hot water coil with valve or electrical heaters has been bought.
Connect only a clean contact.
On/off contacts (at distance – dehumidification – heating) have to be set on the board during the
first start; please make reference to the dedicated chapter.
ESAMPLES:
- The user ask to turn on / turn off the unit from a on-wall switch: I decide to use the on/off at distance, connect the 2
cables of the switch to the clamps 105 -106 and during the first start of the unit activate the on/off at distance.
- I have a drive board from the thermo-regulation of the plant with a clean contact for the dehumidificaion and a clean
contact for the heating: I decide to use the dehumidification on/off contact and the heating on/off contact, connect the
contact to the drive board for the activation of the heating on the clamps 109 – 110 and during the first start activate the
contact for dehumidification an heating.
