RS Dehumidifiers for radiant systems
10 - 52
2.3 OPERATING LIMITATIONS
2.4 OPTIONS
2.4.1 Formwork (only for vertical units)
It is a galvanized steel formwork for installation in the wall. It aims to contain the unit and it has all the holes necessary for hydraulic
and electrical connections. It has also the splines in order to allow an optimal fixing on the wall.
2.4.2 White lacquered wooden panel (only for vertical units)
It is a white lacquered wooden panel with holes for suction and supply air. It is suitable for the formwork.
2.4.3 Painted steel sheet panel with plastic grills (only for vertical units)
It is a white galvanized panel, with plastic grills for suction and supply air. It is suitable for the formwork.
2.4.4 Supply plenum (only for vertical units)
A supply plenum allows the canalization of the supply air with flexible spiral pipe. (More information contacting our offices).
2.4.5 Mechanical humidistat
It is an external device to be installed on the wall and it manages the activation of the unit.
Humidity operating range: 30 – 99% RH, precision +/- 3 %.
2.4.6 RS485 serial port
The bus RS485 connection is available to control the unit at distance or by a home automation plant.
(More information contacting our offices).
2.4.7 Supply flange (only for horizontal units)
It is a supply flange to make easier the connection of the unit with ducts for air distribution.
5
10
15
20
25
30
35
35 40 45 50 55 60 65 70 75 80 85 90 95 100
Internal air Temperature [°C]
Internal air humidity [%]
