HiDew RSO - 10.5 RSE 050

USER MANUAL - rev 10
RS Dehumidifiers for radiant systems
45 - 52
10.5 RSE 050
10.5.1 RSE 050
Air suction
Inspection and maintenance panels
condensate drain
Delivery air
TOP VIEW
Air supply
Air suction
Fan regulation
Electrical panel
Control
Inspection and maintenance panels
Hydraulic circuit air vent valve
Hydraulic circuit air vent valve
Water outlet to radiant system
1/2" Gas female
Water inlet from radiant system 1/2"
Gas female)
