HiDew RSO - 10.6 RSE 100

USER MANUAL - rev 10
RS Dehumidifiers for radiant systems
47 - 52
10.6 RSE 100
10.6.1 RSE 100
Air supply
TOP VIEW
n°4 fixing holes
Air supply
condensate drain
Water outlet to radiant system
1/2" Gas female
Hybrid version I
Water inlet from radiant system 1/2"
Gas female
Isothermal version A
control
Fan regulation
Electrical panel
