HiDew RSO - 10.7 Formwork RSV - RSVE 020; 10.8 Formwork RSV - RSVE 035

USER MANUAL - rev 10
RS Dehumidifiers for radiant systems
49 - 52
10.7 FORMWORK RSV – RSVE 020
10.7.1 Formwork and wooden panel RSV – RSVE 020
10.8 FORMWORK RSV – RSVE 035
10.8.1 Formwork and wooden panel RSV – RSVE 035
Wall
Formwork
Inlet area for hydraulic and electrical
connections and for condensate drain
Panel
Dehumidifier
Dehumidifier
Formwork
Inlet area for hydraulic and electrical
connections and for condensate drain
Panel
Wall
