RS Dehumidifiers for radiant systems
29 - 52
9.2.5 Ceiling installation
In order to avoid vibration and noise transmission, it is
recommended use of rubber anti-vibration dampers on
each fixing point.
9.2.6 Installation of the unit in the formwork [optional]
In order to avoid vibration and noise transmission, it is
recommended use of a layer of insulating material between
formwork and unit.
9.2.7 Fan panel rotation for top supply
When it is required top supply for units RSV refer to the following instructions (this configuration is standard in units RSVE).
Before operating on the unit cut off the voltage.
Do not remove any other screws.
After modification of the unit, before switching on the voltage, it is necessary to check the fan.
Try to rotate the fan by hand and check that nothing blocks fan rotation.
In line supply unit
(RSV standard configuration)
Top supply unit
(result of modification)
Unscrew the screws on the panel
Detach fixing clips behind the control,
extract and rotate it.
Install fixing clips.
Fixing clips of the control
