ASSEMBLY INSTRUCTIONS
VERTICAL LIFTING PLATFORM PH-300
Vertical, continuous and solid, for R>500 (d= 80÷400)
1.5÷5≤1.5
≤15º
d=80÷400A
40
d=80÷400
1100
Permitted projection dimensions
for wall without projections
(for d=80÷120 only)
Vertical, continuous and solid, for R≤ 500 (d= 20÷400)
1.5÷5≤1.5
≤15º
Permitted projection dimensions
for wall without projections
(for d=20÷120 only)
d=20÷400
d=20÷400A
