Higen FDA7004B - Extra Large Type Servo Drive

2. Wiring and connection
2-12
< Drawing C> Order Code : FDA600010S (FDA7110, 1600W/4 Ω)
FDA600011S (FDA7150, 2000W/3 Ω)
2.3.2. Extra large type servo drive
(a) Main Circuit Terminal (b) Control Circuit Terminal
[FDA7220-H Terminal]
(a) Main Circuit Terminal (b) Control Circuit Terminal
[FDA7300-H ~ FDA7450-H Terminal]
