Higen FDA7004B - 15 Line Incremental Encoder

2. Wiring and connection
2-25
2.6.1. 15line Incremental encoder
CN2
PIN No.
(Drive)
Signal name
(Drive)
MOTOR(□60,80series) side
Connector pin No. for encoder.
MOTOR(□130,180series) side
Connector pin No. for encoder.
1
PW
11
P
2
/PW
12
R
3
PV
9
M
4
/PV
10
N
5
PU
7
K
6
/PU
8
L
7
8
9
GND
14
G
10
11
/PZ
6
F
12
Shield
15
J
13
/PB
4
D
14
PZ
5
E
15
/PA
2
B
16
PB
3
C
17
18
PA
1
A
19
Vcc( DC 5V )
13
H
20
