Higen FDA7015 User Manual

3. Parameter setting
3-2
[ First and second space value ]
Upper
menu name
P01 P02 P03 P04 P05 P06 P07 P08 P09 JOG ALS StE
1
st
and 2
nd
value
01 02 03 04 05 06 07 08 09 10 11 12
Refer to each parameter for the third and fourth menu number.
StE-02
Command Speed
Unit
rpm
Display range
-9999.9 ~ 9999.9
Manufactured
default
-
Speed/position
control
StE-03
Motor Speed
Unit
rpm
Display range
-9999.9 ~ 9999.9
Manufactured
default
-
Speed/Torque/
Position control
StE-04
CCW Speed Limit
Unit
rpm
Display range
0.0 ~ 9999.9
Manufactured
default
-
Speed/Torque/
Position control
StE-05
CW Speed Limit
Unit
rpm
Display range
-9999.9 ~ 0.0
Manufactured
default
-
Speed/Torque/
Position control
StE-06
Command Pulse
Unit
pulse
Display range
-99999 ~ 99999
Manufactured
default
-
Position control
StE-07
Feedback Pulse
Unit
pulse
Display range
-99999 ~ 99999
Manufactured
default
-
Position control
StE-08
Error Pulse
Unit
pulse
Display range
-99999 ~ 99999
Manufactured
default
-
Position control
StE-09
Command Torque
Unit
%
Display range
-300.0 ~ 300.0
Manufactured
default
-
Speed/Torque/
Position control
StE-10
Load Rate
Unit
%
Display range
-300.0 ~ 300.0
Manufactured
default
-
Speed/Torque/
Position control
StE-11
Max Load Rate
Unit
%
Display range
-300.0 ~ 300.0
Manufactured
default
-
Speed/Torque/
Position control
StE-12
CCW TRQ LMT
Unit
%
Display range
0.0 ~ 300.0
Manufactured
default
-
Speed/Torque/
Position control
StE-13
CW TRQ LMT
Unit
%
Display range
-300.0 ~ 0.0
Manufactured
default
-
Speed/Torque/
Position control
StE-14
Inertia Ratio
Unit
-
Display range
0.0 ~ 50.0
Manufactured
default
2.0
Speed/Torque/
Position control
StE-15
MULTI Turns
Unit
rev
Display range
0 ~ 99999
Manufactured
default
-
Speed/Torque/
Position control
StE-16
Single Turn
Unit
-
Display range
0 ~ 999999
Manufactured
default
-
Speed/Torque/
Position control
