Higen FDA7030 User Manual

3. Parameter setting
3-10
P02-10
Notch Filter 1
Unit
-
Display range
0 ~ 2
Manufactured
default
0
Speed/Torque/
Position control
The operation of the notch filter is set to operate the notch filter to reduce the resonance of
the machinery.
Set value Operation explanation
0 Do not use the notch filter 1.
1
Operate the notch filter 1 in the set resonance frequency and resonance
bandwidth.
2
This is the method of reducing the resonance after automatically detecting
the resonance frequency, it automatically detects the frequency of which
the vibration is generated and reduces the resonance (Automatically
switches from mode 2 Î 1).
P02-11
NF Frequency 1
Unit
Hz
Display range
50.0 ~ 2000.0
Manufactured
default
300.0
Speed/Torque/
Position control
This sets the notch filter frequency 1 to reduce the resonance of the machinery.
P02-12
NF Bandwidth 1
Unit
%
Display range
10.0 ~ 99.9
Manufactured
default
95.0
Speed/Torque/
Position control
It shows the certain gain bandwidth where the notch filter 1 operate to reduce the resonance of
machinery.
P02-13
Notch Filter2
Unit
-
Display range
0 ~ 1
Manufactured
default
0
Speed/Torque/
Position control
Set the notch filter 2 to reduce the resonance of the machinery.
Set value Operation explanation
0
Do not use the notch filter 2.
1
Operate the notch filter 2 in the set resonance frequency and resonance
bandwidth.
P02-14
NF Frequency 2
Unit
Hz
Display range
50.0 ~ 2000.0
Manufactured
default
500.0
Speed/Torque/
Position control
This sets the notch filter frequency 2 to reduce the resonance of the machinery.
