4. Connect the video output cable to the monitor. Connect the power cable to
the power supply.
5. Adjust the Lens.
1). Loosen the adjustable nut.
2). Adjust the camera from pan direction which is 0~360°adjustable.
3). Adjust the camera from tilt direction which is 0~90°adjustable.
4). Rotate 0~360° to adjust the lens to the surveillance angle.
5). Tighten the adjustable nut to complete the installation.
3-axis Adjustment Figure 2-3
2.2 Installation of HD-SDI Dome Camera
Steps:
1. Drill the screw holes on the ceiling according to the drill template.
To Next Page
