Page #31 background image
HD-SDI Camera·User Manual
31
MOTION
SELECT AREA 1
DISPLAY ON
SENSITIVITY ----|---- 30
MOTION VIEW ON
DEFAULT 
RETURN RET
Motion Detection Figure 3-12
Set a Motion Detection Area:
Steps:
1. Move the cursor to DISPLAY, and press OK button to enter the motion
detection edit interface.
2. Press the OK button to up/down/left/right to define the position of the
selected motion area.
3. Press OK button again to enter the area size configuration interface after the
position is defined.
4. Press the OK button up/down/left/right to define the size of the selected area.
5. Select RET to return to the previous menu, or select AGAIN to re-configure the
motion detection area.
SELECT
3 motion detection areas are selectable. Press the OK button left/right to select
the area.
