HIKVISION DS-2CC11D3S-IR User Manual

HD-SDI Camera·User Manual
38
38
 RED GAIN
0 to 100 are selectable.
MONITOR LCD
GAMMA USER 1
BLUE GAIN ----|----50
RED GAIN ----|----50
RETURN RET
Monitor LCD Figure 3-19
 GAMMA
Gamma is the name of a nonlinear operation used to code and decode
luminance or tristimulus values in video or still image system
1.00, 0.95, 0.90, 0.85, 0.80, 0.75, 0.70, 0.65, 0.60, 0.55, 0.50, 0.45, USER1, USER2,
and AUTO are selectable.
 BLUE GAIN
The value of the blue gain is between 0 and 100.
 RED GAIN
The value of the red gain is between 0 and 100.

HIKVISION DS-2CC11D3S-IR Specifications

General

Brand	HIKVISION
Model	DS-2CC11D3S-IR
Category	Security Camera
Language	English
