HIKVISION DS-2CD752MF-IFB Installation Manual

Installation Manual of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
15
2.5 Mini Dome Camera Physical Description
Camera description:
Figure 2.5.1
Serial NO.
Description
1
Back box
2
Lens
3
P: Power LED indicator, It turns solid red when power is applied to the unit.
4
Bottom board
5
Bottom board set screw hole
6
Lens set screw
7
S & L: Network status LED indicator.
When the network is connected, the “S” LED turns solid orange, while the “L” LED flickers in
green.
8
RESET: Reset all parameters to factory default settings.
Note:
When the camera is power up, press the ‘RESET’ button for about 10 seconds, then all parameters,
including user name, password, IP address, port number, etc., will be reset to the factory default
settings.
Camera connection:
