Installation Manual of Network Camera
© Hikvision Digital Technology Co., Ltd. All Rights Reserved.
Figure 3.2.11
3.3 Bullet Camera Installation
Bullet camera can be fixed in both wall and ceiling, customers can choose different ways to install
the camera according to their specific needs. The following section introduces the wall mounting,
and the ceiling mounting follows the same way:
Step 1: Fix the camera wire hidden box to the wall.
Fig 3.3.1 Fix camera wire hidden box
Note:
If it is cement wall, you need to fix the expand bolt (note: the mounting hole of the expand bolt
should align with the wire hidden box) before fixing wire hidden box as shown in Figure 3.3.1. If the
wall surface is wooden, you can use the self-tapping screw to fix the wire hidden box directly. Please
note that the wall on which the camera is fixed should be able to bear at least three times the
