User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
8
Items Specifications
Wireless
Standard IEEE802.11 a/n(2T2R 300Mbps)
Operation frequency 5.15 to 5.25GHz
Modulation mode 802.11 a/n: OFDM
Antenna Internal, Gain 15dBi,H:40° V:15°
Output power
Receive sensitivity -74dBm@65Mbps, -96dBm@6Mbps
Data rate
11n:13.5/15/27/30/40.5/45/54/60/81/90/108/120/121.5/135/150/162/180/2
16/240/270/300Mbps(40MHz)
130/117/104/78/65/58.5/52/39/26/13/6.5Mbps(20MHz)
11a :54/48/36/24/18/12/9/6Mbps(Auto)
Hardware
Power supply 24V/0.5A PoE
Interface PoE*1+LAN*1
Operation temperature -30℃ to 75℃(-22℉ to 167℉ )
Storage temperature -40℃ to 85℃(-40℉ to 185℉)
Operation humidity 5% to 95%RH non-condensing
Dimensions 270x40x88mm(10.6x1.57x3.46inch)
Software
Encryption 802.1x/WPA-PSK/WPA2-PSK
Network mode Router/Bridge
Operation mode Access Point, Station, WDS Access Point, WDS Station
Security IP/MAC filter, SSID hidden
Network protocol TCP/UDP/ARP/ICMP/DHCP/HTTP/NTP
TDMA
Supported (Avoid 802.11 hidden-node problems, and improve the point-to-
multi-point performance)
Auto ACK timing adjust
Supported(It can automatically choose optimized parameter in long distance
transmission, keep the performance always the best)
Management and Logs NTP, Syslog, Telnet, AC
Web based
configuration
Supported
Firmware update Support update firmware by Web page
Bandwidth supported 5M/10M/20M/40MHz
The Max E.I.R.P about 21dBm
