User Manual of DS-3WF03C-D Outdoor Video Wireless Network Bridge
26
Chapter 7 Network
7.1
Router Mode
DS-3WF03C-D acts as a router when configured to Router mode. In router mode, the
connection is shown in figure. User needs to connect the POE port of POE adaptor to the
POE port of the DS-3WF03C-D.
After the above connection, the DS-3WF03C-D can work as a router. The LAN2 port of
DS-3WF03C-D device acts as the LAN port of the router, and LAN port of POE adaptor
acts as the WAN port of the router.
Figure 7-1 Connection figure of router mode
The Network page is shown in figure.
