2) Click Draw Area and draw a quadrilateral in the preview window by specifying four vertexes
of the detecon region.
3) Adjust Sensivity. Sensivity: Range [0-100]. The higher the value is, the more easily the
detecon alarm can be triggered.
6. Set the arming schedule.
7. Set the linkage
acons.
8. Click Apply.
Region Exing Detecon
Region exing detecon funcon detects people, vehicle or other objects which exit from a pre-
dened
virtual region, and some certain acons can be taken when the alarm is triggered.
Steps
1. Go to Conguraon → Event → Smart Event → Region Exing .
2. Select Camera to
congure.
3. Check Enable Region Exing Detecon.
4. Check Save VCA Picture to save the captured pictures of VCA detecon.
5. Set the detecon rules and detecon areas.
1) Select Arming Area. Up to 4 arming areas are selectable.
2) Click Draw Area and draw a quadrilateral in the preview window by specifying four vertexes
of the
detecon region.
3) Adjust Sensivity. Sensivity: Range [0-100]. The higher the value is, the more easily the
detecon alarm can be triggered.
6. Set the arming schedule.
7. Set the linkage
acons.
8. Click Apply.
Loitering
Detecon
Loitering detecon funcon detects people, vehicle or other objects which loiter in a pre-dened
virtual region for some certain me, and a series of acons can be taken when the alarm is
triggered.
Steps
1. Go to Conguraon → Event → Smart Event → Loitering .
2. Select Camera to
congure.
3. Check Enable Loitering Detecon.
4. Check Save VCA Picture to save the captured pictures of VCA
detecon.
5. Set the detecon rules and detecon areas.
1) Select Arming Area. Up to 4 arming areas are selectable.
2) Click Draw Area and draw a quadrilateral in the preview window by specifying four vertexes
of the
detecon region.
3) Adjust Threshold and
Sensivity.
Digital Video Recorder User Manual
60
