Table 1-1 Panel Description
Turns red when a sensor alarm is detected.
Turns blue when the device is functioning
properly.
Turns blue when device is controlled by an IR
remote.
Turns red when controlled by a keyboard and
purple when IR remote and keyboard is used at
the same time.
Flickers red when data is being read from or
written to HDD.
Reserved for future usage.
Flickers blue when network connection is
functioning properly.
Turns blue when the device is in armed status;
at this time, an alarm is enabled when an event
is detected.
Turns off when the device is unarmed. The
arm/disarm status can be changed by pressing
and holding on the ESC button for more than 3
seconds in live view mode.
Receiver for IR remote control.
Locks or unlocks the panel by the key.
Switches to the corresponding channel in live
view or PTZ control mode.
Inputs numbers and characters in edit mode.
Switches between different channels in
playback mode.
Turns blue when the corresponding channel is
recording; turns red when the channel is in
network transmission status; turns pink when
the channel is recording and transmitting.
