Digital Video Recorder User Manual
119
This chapter is applicable to DS-7300HQHI-F/N and DS-8100HQHI-F/N series DVR only.
9.1 Configuring POS Settings
Steps:
1. Enter the POS settings interface.
Menu > Configuration > POS> POS Settings
2. Select the POS from the drop-down list. Up to 8 POS units are selectable.
3. Check the checkbox to enable the POS feature.
Figure 9. 1 POS Settings
4. Select the POS protocol to Universal Protocol, EPSON or AVE.
Universal Protocol
Click the Advanced button to expand more settings when selecting the universal protocol. You can set the
start line tag, line break tag and end line tag for the POS overlay characters, and the case-sensitive property
of the characters.
Figure 9. 2 Universal Protocol Settings
5. Select the connection mode to TPC, UDP, Multicast, RS-232, USB->RS-232 or Sniff, and click Settings to
configure the parameters for each connection mode.
TCP Connection
When using TCP connection, the port must be set from 0 to 65535, and the port for each POS machine
must be unique.
