DS-7200HQHI-F2/N
Model
DS-7208HQHI-F2/N
DS-7216HQHI-F2/N
Video/Audio input
Video
compression
H.264+/H.264
Video input
8-ch
16-ch
BNC interface (1.0Vp-p, 75 Ω), supporting coaxitron connection
Supported
HDTVI input
1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz
Supported AHD
input
720p/25Hz, 720p/30Hz
CVBS input
Support
IP video input
2-ch
Up to 2.0 MP resolution
Audio
compression
G.711u
Audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio output
CVBS output
Support
HDMI/VGA
output
1-ch, 1920 × 1080/60 Hz, 1280 ×
1024/60 Hz, 1280 × 720/60Hz, 1024 ×
768/60 Hz
1-ch, 4K (3840 × 2160)/30Hz, 2K
(2560 × 1440)/60Hz, 1920 × 1080/60
Hz, 1280 × 1024/60 Hz, 1280 ×
720/60Hz, 1024 × 768/60 Hz
Encoding
resolution
When 1080p Lite mode not enabled:
1080p(non-real-time)/720p(non-real-time)/VGA/WD1/4CIF/CIF;
When 1080p Lite mode enabled:
1080p lite/720p lite/VGA/WD1/4CIF/CIF
Frame rate
Main stream: 25fps (P)/30fps (N)
Sub-stream: WD1/4CIF@12fps/2CIF (non-real-time); CIF/QVGA/QCIF (real
time)
Video bit rate
32 Kbps to 6 Mbps
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio bit rate
64 Kbps
Dual-stream
Support;
Stream type
Video, Video & Audio
Synchronous
playback
8-ch
16-ch
Network
management
Remote
connections
128
Network
protocols
TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, NFS,
iSCSI, UPnP™, HTTPS
Hard disk
SATA
2 SATA interfaces
Capacity
Up to 6TB capacity
External interface
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the audio input)
Network
interface
1, RJ45 10M/100M self-adaptive
Ethernet interface
1, RJ45 10M/100M/1000M
self-adaptive Ethernet interface
USB interface
2 × USB 2.0
Front panel: 1× USB 2.0
Rear panel: 1× USB 3.0
Serial interface
1; RS-485 serial interface, half-duplex
General
Power supply
12 VDC
Consumption
(without HDD)
≤ 20W
≤ 30W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working
humidity
10% to 90%
Dimensions
(W × D × H)
380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch)
Weight
(without HDD)
≤ 2 kg (4.4lb)
≤ 2 kg (4.4lb)
