HIKVISION DS-7108HGHI-E1 User Manual

Digital Video Recorder User Manual
208
DS-7200HUHI-F1/N
Model
DS-7204HUHI-F1/N
DS-7208HUHI-F1/N
Video/Audio input
Video compression
H.264+/H.264
Video input
4-ch
8-ch
BNC interface (1.0Vp-p, 75 Ω), supporting coaxitron connection
Supported HDTVI
input
1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz,
720p/60Hz, 3MP, 5MP
Supported AHD input
720p/25Hz, 720p/30Hz
CVBS input
Support
IP video input
2-ch
Up to 4.0 MP resolution
Audio compression
G.711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio output
CVBS output
Support
HDMI/VGA output
VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60 Hz
HDMI: 1-ch, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
HDMI: 1-ch, 4K (3840 ×
2160)/30Hz, 2K (2560 ×
1440)/60Hz, 1920 × 1080/60Hz,
1280 × 1024/60Hz, 1280 ×
720/60Hz, 1024 × 768/60Hz
Encoding resolution
5MP@12fps/3MP@15fps/1080p/720p/WD1/4CIF/VGA/CIF
Note: For DS-7204HUHI-F1/N, only channel 1 supports 5MP resolution.
For DS-7208HUHI-F1/N, only channel 1 and 5 support 5MP resolution.
Frame rate
Main stream: 25 fps (P)/30 fps (N)
Sub-stream: WD1/4CIF@12fps (non-real-time); CIF/QVGA/QCIF (real
time)
Video bitrate
32 Kbps to 10 Mbps
Audio output
1-ch, RCA (Linear, 1 KΩ)
Audio bit rate
64 Kbps
Dual-stream
Support
Stream type
Video, Video & Audio
Synchronous playback
4-ch
8-ch
Network
management
Remote connections
128
Network protocols
TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP,
NFS, iSCSI, UPnP™, HTTPS, ONVIF
Hard disk
SATA
1 SATA interface
Capacity
Up to 6TB capacity
External interface
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the audio input)
Network interface
1, RJ45 10M/100M self-adaptive
Ethernet interface
1, RJ45 10M/100M/1000M
self-adaptive Ethernet interface
USB interface
2 × USB 2.0
Front panel: 1× USB 2.0
Rear panel: 1×USB 3.0
Serial interface
1; RS-485 serial interface, half-duplex
Alarm in/out
4/1
8/4
General
Power supply
12 VDC
Consumption
(without HDD)
≤ 15W
≤ 20W
Working temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF)
Working humidity
10% to 90%
Dimensions
(W × D × H)
315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)
Weight
(without HDD)
≤ 1.5 kg (3.3 lb)
≤ 2 kg (4.4 lb)

HIKVISION DS-7108HGHI-E1 Specifications

General

Brand	HIKVISION
Model	DS-7108HGHI-E1
Category	DVR
Language	English
