Digital V
ideo Recorder User Manual
125
8.
S
elect
PTZ Linkin
g
tab and set PTZ linkage of the POS alarm.
Set PTZ linking parameters and click the
OK
button to complete the settings of the alarm input.
Please check whether the PTZ or speed dome supports PTZ linkag
e.
Figure 9. 14
Set PTZ Linking
9.
Cli
ck
OK
to save the settings.
125
