Instant Playback only shows the record in last five minutes. If no record is found, it means there is no record
during the last five minutes.
Digital Zoom can zoom in the selected area to the full screen. Click and draw to select the area to zoom in, as
shown in Figure 3. 4.
Figure 3. 4 Digital Zoom
Image Settings icon can be selected to enter the Image Settings menu. You can drag the mouse or click to
adjust the image parameters, including brightness, contrast, and saturation. Refer to the Chapter 14.3 Configuring
Video Parameters for details.
Figure 3. 5 Image Settings
Face Detection can be enabled if you click the icon. The dialog pops up as shown in Figure 3.6. Click Yes
and the full-screen live view of the channel is enabled. You can click to exit from the full-screen mode.
