Network Video Recorder User Manual
147
Up to 4 rules can be configured.
Step 8 Click Apply to save the settings.
9.5 Region Exiting Detection
Purpose:
Region exiting detection function detects people, vehicle or other objects which exit from a
pre-defined virtual region, and some certain actions can be taken when the alarm is triggered.
Please refer to the Chapter 9.5 Region Entrance Detection for operating steps to configure
the region exiting detection.
Up to 4 rules can be configured.
9.6 Unattended Baggage Detection
Purpose:
Unattended baggage detection function detects the objects left over in the pre-defined region
such as the baggage, purse, dangerous materials, etc., and a series of actions can be taken when
the alarm is triggered.
Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the
unattended baggage detection.
The Threshold [5s-20s] in the Rule Settings defines the time of the objects left over in the
region. If you set the value as 10, alarm is triggered after the object is left and stay in the
region for 10s. And the Sensitivity defines the similarity degree of the background image.
Usually, when the sensitivity is high, a very small object left in the region can trigger the
alarm.
Up to 4 rules can be configured.
9.7 Object Removal Detection
Purpose:
Object removal detection function detects the objects removed from the pre-defined region, such
as the exhibits on display, and a series of actions can be taken when the alarm is triggered.

Table of Contents

Other manuals for HIKVISION DS-7616NI-Q2/16P

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7616NI-Q2/16P and is the answer not in the manual?

HIKVISION DS-7616NI-Q2/16P Specifications

General IconGeneral
DHCP clientYes
Input bandwidth160 Mbit/s
Output bandwidth80 Mbit/s
Maximum resolution3840 x 2160 pixels
Video input channels16 channels
Alarm output channels1
Supported resolutions3840 × 2160, 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Video recording modes720p, 1080p
Video formats supportedH.264, H.264+, H.265, H.265+, MPEG4
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Supported network protocolsTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Product colorBlack
Rack capacity1U
AC input voltage100 - 240 V
Power consumption (max)280 W
Total Power over Ethernet (PoE) budget150 W
Wi-FiNo
HDD interfaceSerial ATA
Maximum storage capacity16 TB
Number of HDDs supported2
Total installed storage capacity1000 GB
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth315 mm
Width385 mm
Height52 mm
Weight3000 g
