Network Video Recorder User Manual
82
5.2 Configuring Recording Schedule
Purpose:
Set the record schedule, and then the camera automatically starts/stops recording according to the
configured schedule.
In this chapter, we take the record schedule procedure as an example, and the same procedure can
be applied to configure schedule for both recording and capture. To schedule the automatic
capture, you need to choose the Capture tab in the Schedule interface.
Step 1 Enter the Record Schedule interface.
Menu>Record >Schedule
Step 2 Configure Record Schedule
1) Select Record Schedule.
Different recording types are marked in different color icons.
Continuous: scheduled recording.
Event: recording triggered by all event triggered alarm.
Motion: recording triggered by motion detection.
Alarm: recording triggered by alarm.
M/A: recording triggered by either motion detection or alarm.
M&A: recording triggered by motion detection and alarm.
You can delete the set schedule by clicking the None icon.
2) Choose the camera you want to configure.
3) Select the check box after the Enable Schedule item.
4) Click Edit button or click on the color icon under the edit button and draw the schedule
line on the panel.
Edit the schedule:
