HIKVISION DS-7616NI-Q2/16P User Manual

Network Video Recorder User Manual
19
Table 1-4 IR Remote Functions
No.
Name
Function Description
1
POWER
ON/OFF
• To Turn Power On:
- If User Has Not Changed the Default NVR Device ID# (255):
1. Press Power On/Off button (1).
- If User Has Changed the NVR Device ID#:
1. Press DEV button.
2. Press Number buttons to enter user-defined Device ID#.
3. Press Enter button.
4. Press Power button to start device.
• To Turn NVR Off:
- If User Is Logged On:
1. Hold Power On/Off button (1) down for five seconds to
display the “Yes/No” verification prompt.
2. Use Up/Down Arrow buttons (12) to highlight desired
selection.
3. Press Enter button (12) to accept selection.
- If User Is Not Logged On:
1. Hold Power On/Off button (1) down for five seconds to
display the user name/password prompt.
2. Press the Enter button (12) to display the on-screen keyboard.
3. Input the user name.
4. Press the Enter button (12) to accept input and dismiss the
on-screen keyboard.
5. Use the Down Arrow button (12) to move to the “Password”
field.
6. Input password (use on-screen keyboard or numeric buttons
(3) for numbers).
7. Press the Enter button (12) to accept input and dismiss the
on-screen keyboard.
8. Press the OK button on the screen to accept input and display
the Yes/No” verification prompt (use Up/Down Arrow buttons
(12) to move between fields)
9. Press Enter button (12) to accept selection.

HIKVISION DS-7616NI-Q2/16P Specifications

General

DHCP client	Yes
Input bandwidth	160 Mbit/s
Output bandwidth	80 Mbit/s
Maximum resolution	3840 x 2160 pixels
Video input channels	16 channels
Alarm output channels	1
Supported resolutions	3840 × 2160, 1920 × 1080, 1600 × 1200, 1280 × 1024, 1280 × 720, 1024 × 768
Video recording modes	720p, 1080p
Video formats supported	H.264, H.264+, H.265, H.265+, MPEG4
Networking standards	IEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols	TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
Product color	Black
Rack capacity	1U
AC input voltage	100 - 240 V
Power consumption (max)	280 W
Total Power over Ethernet (PoE) budget	150 W
Wi-Fi	No
HDD interface	Serial ATA
Maximum storage capacity	16 TB
Number of HDDs supported	2
Total installed storage capacity	1000 GB
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	315 mm
Width	385 mm
Height	52 mm
Weight	3000 g
