Network Video Recorder User Manual
142
 Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the fast moving detection.
 The Sensitivity in the Rule Settings defines the moving speed of the object which can trigger the alarm. The
higher the value is, the more easily a moving object can trigger the alarm.
 Up to 4 rules can be configured.
9.10 Parking Detection
Purpose:
Parking detection function detects illegal parking in places such as highway, one-way street, etc., and a series of
actions can be taken when the alarm is triggered.
 Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the parking detection.
 The Threshold[5s-20s] in the Rule Settings defines the time of the vehicle parking in the region. If you set
the value as 10, alarm is triggered after the vehicle stay in the region for 10s.
 Up to 4 rules can be configured.
9.11 Unattended Baggage Detection
Purpose:
Unattended baggage detection function detects the objects left over in the pre-defined region such as the baggage,
purse, dangerous materials, etc., and a series of actions can be taken when the alarm is triggered.
 Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the unattended baggage
detection.
 The Threshold[5s-20s] in the Rule Settings defines the time of the objects left over in the region. If you set
the value as 10, alarm is triggered after the object is left and stay in the region for 10s. And the Sensitivity
defines the similarity degree of the background image. Usually, when the sensitivity is high, a very small
object left in the region can trigger the alarm.
 Up to 4 rules can be configured.
9.12 Object Removal Detection
Purpose:
Object removal detection function detects the objects removed from the pre-defined region, such as the exhibits on
display, and a series of actions can be taken when the alarm is triggered.

HIKVISION DS-7716NI-E4/16P Specifications

General

Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	16
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
Video formats supported	H.264+
Audio RCA inputs	1
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Card reader integrated	No
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Product color	Black
Rack capacity	1.5U
HDD capacity	4 GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Total installed storage capacity	16000 GB
AC input voltage	100 - 240 V
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	4000 g
