Network Video Recorder User Manual
6
Product Key Features
General
 Connectable to network cameras, network dome and encoders.
 Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Bosch, Brickcom, Canon,
PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO, and cameras that adopt ONVIF
or PSIA protocol.
 Connectable to the smart IP cameras.
 PAL/NTSC adaptive video inputs.
 Supports H.264/H.264+ video streams.
 Each channel supports dual-stream.
 Up to 32 network cameras can be connected for DS-8600NI-E8, DS-7700NI-E4 and DS-7600NI-E2 series
NVR; 16 network cameras for other DS-7600NI models.
 Independent configuration for each channel, including resolution, frame rate, bit rate, image quality, etc.
 The quality of the input and output record is configurable.
Local Monitoring
 Simultaneous HDMI
TM
and VGA outputs.
 HDMI
TM
and VGA outputs at up to 1920×1080 resolution.
 Multiple screen display in live view is supported, and the display sequence of channels is adjustable.
 Live view screen can be switched in group, and manual switch and automatic cycle live view are also
provided, and the interval of automatic cycle can be adjusted.
 Quick setting menu is provided for live view.
 Motion detection, video tampering, VCA (Video Content Analysis) alarm, video exception alert and video
loss alert functions.
 Privacy mask.
 Multiple PTZ protocols supported; PTZ preset, patrol and pattern.
 Zooming in by clicking the mouse and PTZ tracing by dragging mouse.
The PTZ control is supported by the DS-8600NI-E8 and DS-7700NI-E4 series NVR only.
HDD Management
 For DS-8600NI-E8 series, 8 SATA hard disks can be connected;
For DS-7700NI-E4 series, 4 SATA hard disks can be connected;
For DS-7600NI-E2 series, 2 SATA hard disks can be connected;
For DS-7600NI-E1 series, 1 SATA hard disk can be connected;
 Each disk with a maximum of 6TB storage capacity for the DS-8600NI-E8, DS-7700NI-E4,
DS-7600-E1(E2) series NVR.
 8 network disks (NAS /IP SAN disks) can be connected.
 Supports S.M.A.R.T. and bad sector detection.
 HDD group management.
 Supports HDD standby function.
 HDD property: redundancy, read-only, read/write (R/W).
 HDD quota management; different capacity can be assigned to different channel.
Recording and Playback
 Holiday recording schedule configuration.

HIKVISION DS-7716NI-E4/16P Specifications

General

Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	16
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
Video formats supported	H.264+
Audio RCA inputs	1
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Card reader integrated	No
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Product color	Black
Rack capacity	1.5U
HDD capacity	4 GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Total installed storage capacity	16000 GB
AC input voltage	100 - 240 V
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	4000 g
