HIKVISION DS-7716NI-E4/16P User Manual

Network Video Recorder User Manual
224
DS-7600NI-E2/N
Model
DS-7616NI-E2/8N
DS-7632NI-E2/8N
DS-7616NI-E2/16N
DS-7632NI-E2/16N
Video/Audio
input
IP video input
16-ch
32-ch
16-ch
32-ch
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming
bandwidth
160 Mbps
Outgoing
bandwidth
80 Mbps
Remote
connection
128
Video/Audio
output
Recording
resolution
6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P)/60 fps (N)
Sub-stream: 50 fps (P)/60 fps (N)
HDMI/VGA
output
1-ch, resolution:
1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Decoding
Live
view/Playback
resolution
6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability
16-ch@4CIF, 12-ch@720p, 6-ch@1080p
Network
management
Network
protocols
TCP/IP, DHCP, PPPoE, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI,
UPnP™, HTTPS
Hard disk
SATA
2 SATA interfaces for 2 HDDs
Capacity
Up to 4TB for each disk
External
interface
Network
interface
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
8 independent 100 Mbps built-in switch
network interfaces
16 independent 100 Mbps built-in switch
network interfaces
USB interface
1 × USB 2.0 and 1 × USB 3.0
Alarm in/out
(Optional)
4/1
General
Power supply
12 VDC
Consumption
(without hard
disk)
≤ 10 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF )
Working
humidity
10 % to 90 %
Chassis
385 mm chassis
Dimensions
(W × D × H)
385 × 315× 52 mm
(15.2" × 12.4" × 2.0")
Weight
(without hard
disk)
≤ 1 kg (2.2 lb)

HIKVISION DS-7716NI-E4/16P Specifications

General

Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	16
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz
Video formats supported	H.264+
Audio RCA inputs	1
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Card reader integrated	No
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Power over Ethernet (PoE)	Yes
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Product color	Black
Rack capacity	1.5U
HDD capacity	4 GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Total installed storage capacity	16000 GB
AC input voltage	100 - 240 V
Power consumption (typical)	20 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	390 mm
Width	445 mm
Height	70 mm
Weight	4000 g
