Network Video Recorder User Manual
16
No.
Name
Function Description
Automatically scans in the PTZ control menu.
Zooms in the PTZ camera in the PTZ control setting.
Adjusts focus in the PTZ Control menu.
Switches between input methods (upper and lower case alphabet,
symbols and numeric input).
Edits text fields. When editing text fields, it also deletes the
character in front of the cursor.
Checks the checkbox in the checkbox fields.
Adjusts the iris of the camera in PTZ control mode.
Generates video clips for backup in playback mode.
Enters/exits the folder of USB device and eSATA HDD.
Switches between main and spot output.
Zooms out the image in PTZ control mode.
Selects all items on the list when used in a list field.
Turns on/off PTZ light (if applicable) in PTZ control mode.
Switches between play and reverse play in playback mode.
Cycles through tab pages.
Switches between channels in synchronous playback mode.
Returns to the Main menu (after successful login).
Presses and holds the button for five seconds to turn off audible
key beep.
Starts wiper (if applicable) in PTZ control mode.
Shows/hides the control interface in playback mode.
Switches between single screen and multi-screen mode.
Adjusts the focus in conjunction with the A/FOCUS+ button in
PTZ control mode.
Enters the PTZ Control mode.
Adjusts the iris of the PTZ camera in PTZ control mode.
7
Control
Buttons
Navigates between different fields and items in menus.
In the playback mode, use the Up and Down buttons to speed up
and slow down recorded video. Use the Left and Right buttons
to select the next and previous video files.
Cycles through channels in live view mode.
Controls the movement of the PTZ camera in PTZ control mode.
Confirms selection in any of the menu modes.
Checks the checkbox fields.
Plays or pauses the video playing in playback mode.
Advances the video by a single frame in single-frame playback
mode.
Stops/starts auto switch in auto-switch mode.
8
JOG SHUTTLE Control
Moves the active selection up and down in a menu.
Cycles through different channels in live view mode.
Jumps 30s forward/backward in video files in the playback
mode.
Controls the movement of the PTZ camera in PTZ control mode.
9
POWER ON/OFF
Power on/off switch.
