4.22 Siderail Control Cable
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 51
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
CAUTION:
Use caution when you cut the wire ties. Failure to do so could cause
cable damage.
12. Carefully cut all of the wires ties that attach the siderail cable (I) to the bed
frame (M).
13. Disconnect the siderail cable (I) from the control box assembly (B).
Replacement
CAUTION:
Keep enough slack in the cables to allow the bed to move through its
full range of motion. Make sure the bed cables do not bind and do not
have any force applied to them. Failure to do so could cause equipment
damage.
1. When you route the siderail cable (I), make sure it has enough slack for the
bed to move through its full range of motion.
2. Route the siderail cable (I) from the control box assembly (B) to the
siderail (A).
NOTE:
The connector will not fit through the bracket.
3. Do the removal procedure in the reverse order.
4. Do the “Function Checks” on page 2-2.
