4.27 Casters for Individual Brake and Steer
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 61
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
4.27 Casters for Individual Brake and Steer
Tools required: Phillips head screwdriver
Caster blocks
Bed frame jack
Removal
1. Disconnect the battery cable from the control board (refer to procedure 4.7
on page 4-16).
SHOCK HAZARD:
Disconnect the bed from its power source. Failure to do so could cause
injury or equipment damage.
2. Disconnect the bed from its power source.
WARNING:
Put caster blocks behind the casters at the opposite end of the bed.
Failure to do so could cause injury.
3. Put caster blocks behind the casters at the opposite end of the bed that you
are to work on.
4. Use a jack to lift the end of the bed you are must work on off of the floor.
5. Remove the bolt (A) and washer (B) that attach the caster (C) to the bed
frame (D) (see figure 4-28 on page 4-62).
6. Remove the caster (C) from the bed frame (D).
