Base Frame—Model A
Chapter 5: Parts List
5
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 5 - 13
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
Table 5-3. Base Frame—Model A
Item Number Part Number Quantity Description
1 131439 4 Caster hole covers
2 131427 2 Central brake and steer pedal assembly,
left-hand
3 131424 2 Brake/steer linkage, head end
4 not available 3 Caster hex rod
5 131421 5 Rocker arm assembly—Basic Care
6 131467 2 Brake/steer pedal pad set
7 131425 1 Brake/steer hex rod (center)
8 131433 1 Brake/steer caster (central brake and steer)
9 131430 1 Swivel caster (central brake and steer)
10 131432 2 Brake caster (central brake and steer)
11 131429 3 Individual brake caster
12 131434 1 Individual brake/steer caster
13 131423 1 Brake/steer linkage, foot end
14 131426 2 Central brake and steer pedal assembly,
right-hand
15 141138
141137
4 Caster bolt—without central brake and
steering
Caster bolt—with central brake and
steering
