4.6 Fuses
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 15
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
5. Disconnect the battery cable (D) from the control board (E).
6. Remove the fuse (F) from the fuse assembly (G).
7. Remove the fuse (H) from the control board (E).
Replacement
1. Do the removal procedure in the reverse order.
2. Do the “Function Checks” on page 2-2.
