6 English 2155180
*2155180*
In order to operate the fastening tool, the gas can must be inserted in the gas can compartment.
The gas can status can be read from the LED display after pressing the GAS button.
The gas can must be removed before breaks between working, before maintenance and before transporting
or storing the fastening tool.
3.12 Indication of gas can status
After pressing the GAS button, the LED display indicates the status of the gas can.
The gas level indicator does not operate correctly if the fastener guide / tool nosepeice has been fully
compressed.
Status Meaning
All four LEDs light green. Level is approx. 100 %.
Three LEDs light green. Level is approx. 75 %.
Two LEDs light green. Level is approx. 50 %.
One LED lights green. Level is approx. 25 %.
One LED blinks green. Level is below 10 %. Replacement of the gas can
is recommended.
One LED lights red. There is either no gas can in the fastening tool, the
wrong type of gas can is fitted or the can is empty.
Even when the level is indicated as “empty”, the gas can, for technical reasons, still contains a little gas.
4 Technical data
4.1 Fastening tool
Weight (empty)
3.9 kg
(8.6 lb)
Application temperature, ambient temperature
−10 ℃ … 45 ℃
(14 ℉ … 113 ℉)
Maximum fastener length
39 mm
(1.5 in)
Fastener diameter
• 2.6 mm (0.10 in)
• 3.0 mm (0.12 in)
Compression stroke
40 mm
(1.6 in)
Magazine capacity
40 + 2 nails
Maximum fastener driving frequency (Fasteners per hour)
1,200
Maximum magnetic field strength
−16.5 dBµA/m
Frequency
13,553 MHz … 13,567 MHz
4.2 Noise information and vibration values
The sound pressure and vibration values given in these instructions have been measured in accordance
with a standardized test and may be used to compare one fastening tool with another. They may be used
for a preliminary assessment of exposure. The data given represents the main applications of the fastening
tool. However, if the fastening tool is used for different applications, with different accessories or is poorly
maintained, the data may vary. This may significantly increase exposure over the total working period. An
estimation of the level of exposure should also take into account the periods of time when the tool is not
actually in use. This may significantly reduce exposure over the total working period. Prescribe additional
safety measures to protect the operator from the effects of noise and/or vibration, such as: maintenance of
the direct fastening tool and its additional equipment or accessories, keeping the hands warm, organization
of work patterns.
