7.2 Unloading the magazine
1. Pull the nail pusher back until it engages.
2. Remove all nail strips from the magazine.
WARNING
Risk of finger injury! Fingers could be pinched when the nail pusher is released.
▶ When disengaging the nail pusher, do not release it and allow it to jump forward. Guide it forward slowly
as far as it will go.
3. Release the nail pusher and guide it forward as far as it will go.
7.3 Removing the single-fastener adapter
▶ After driving the fasteners, remove the single-fastener adapter ( → page 10) from the fastening tool.
8 Optional operating steps
8.1 Checking the status of the gas can
1.
Without pressing the fastening tool against the working surface, press the GAS button.
2. Read the gas can status from the display. → page 6
8.2 Removing the magazine
1. Pull the nail pusher back until it engages.
2. Remove the loose nail strips from the magazine.
WARNING
Risk of finger injury! Fingers could be pinched when the nail pusher is released.
▶ When disengaging the nail pusher, do not release it and allow it to jump forward. Guide it forward slowly
as far as it will go.
3. Release the nail pusher and guide it forward as far as it will go.
4. Release the magazine locking catch.
5. Pivot the magazine about the pivot point towards the front.
6. Detach the magazine.
8.3 Fitting the magazine
1. Release the magazine locking catch.
2. Engage the front end of the magazine with the setting tool.
3. Pivot the magazine towards the setting tool as far as it will go.
4. Close the magazine locking catch.
8.4 Removing the support leg
1. Release the support leg engaging mechanism by pressing lightly.
2. Rotate the support leg through 90°.
3. Remove the support leg.
8.5 Fitting the support leg
1. Bring the support leg into contact with the magazine at right angles and guide it into the slot.
2. Rotate the support leg through 90° relative to the magazine and allow it to engage while applying light
pressure.
8.6 Inserting the single-fastener adapter
1. Remove the gas can. → page 8
2. Remove the magazine. → page 9
3. Insert the single-fastener adapter.
4. Fit the magazine. → page 9
