F3 DIO 8/8 01 3 Product Description
HI 800 179 E Rev. 2.00 Page 23 of 52
3.5 Product Data
General
Response time ≥ 10 ms
Ethernet interfaces 2 x RJ-45, 10BASE-T/100BASE-Tx with integrated switch
Operating voltage 24 VDC, -15...+20 %, r
PP
≤ 15 %,
from a power supply unit with safe insulation
in accordance with IEC 61131-2
Current input
max. 8 A (with maximum load)
Idle: approx. 0.4 A at 24 V
Fuse (external) 10 A time-lag (T)
Back-up battery None
Operating temperature 0...+60 °C
Storage temperature -40...+85 °C
Type of protection IP20
Max. dimensions
(without plug)
Width: 152 mm (with housing screws)
Height: 114 mm (with fixing bolt)
Depth: 66 mm (with earthing screw)
Weight approx. 1 kg
Table 11: Product Data
Digital inputs
Number of inputs 8 (non-galvanically separated)
High level: Voltage
Current input
15...30 VDC
≥ 2 mA at 15 V
Low level: Voltage
Current input
max. 5 VDC
max. 1.5 mA (1 mA at 5 V)
Switching point typ. 7.5 V
Supply 2 x 20 V / 100 mA (at 24 V), short-circuit-proof
Table 12: Specifications for Digital Inputs
