HIMA HIMatrix F3 DIO 8/8 01 User Manual

3 Product Description F3 DIO 8/8 01
Page 24 of 52 HI 800 179 E Rev. 2.00
Digital outputs (DO+ and DO-)
Number of outputs DO+
L+ switching
8 (non-galvanically separated)
Common ground L-
Number of outputs DO-
L- switching
2 (non-galvanically separated)
Common ground S+
Output voltage ≥ L+ minus 2 V
Output current DO+ Channels 1...3 and 5...7: 0.5 A up to 60 °C
The output current of the channels 4 and 8 depends on the
ambient temperature.
Ambient temperature Output current
< 40 °C 2 A
40…60 °C 1 A
Output current DO-
The output current of the channels 4 and 8 depends on the
ambient temperature.
Ambient temperature Output current
< 40 °C 2 A
40…60 °C 1 A
Lamp load, max.:
DO+ channel 1...3 and 5...7
DO+ channel 4 and 8
DO- channel 4 and 8
10 W
25 W
25 W
Inductive load, max.:
DO+ channel 1...3 and 5...7
DO+ channel 4 and 8
DO- channel 4 and 8
500 mH
500 mH
500 mH
Minimum load 2 mA for each channel
Internal voltage drop max. 2 V at 2 A
Behavior upon overload
The affected output is switched off and cyclically switched on
again
Total output current
max. 7 A,
upon overload, all outputs are switched off and cyclically
switched on again
Table 13: Specifications for the Digital Outputs
Pulsed outputs
Number of outputs 2 (non-galvanically separated)
Output voltage ≥ L+ minus 4 V
Output current approx. 60 mA
Minimum load none
Switching time ≤ 100 µs
Behavior upon overload 2 x ≥ 19.2 V, short-circuit current 60 mA at 24 V
Table 14: Specifications for the Pulsed Outputs
