4.3.2.2 Tab DO 8 LC: Channels
The DI 8 LC: Channels tab contains the following system parameters.
System parameter
Data
type
R/W Description
Channel no. --- R Channel number, defined by default
-> Error Code
[BYTE]
BYTE R Error codes for the digital input channels
Coding Description
0x01 Fault in the digital input module
0x10 Short-circuit of the channel
0x80
Intermittence between pulsed output TO and
digital input DI, e.g.,
 Open-circuit
 Open switch
 L+ undervoltage
-> Value [BOOL] BOOL R Input values for the digital input channels
0 = input de-energized
1 = input energized
Pulsed Output
[USINT] ->
USINT W Source channel for pulsed supply
Coding Description
0 Input channel
1 Pulse of the 1st TO channel
2 Pulse of the 2nd TO channel
Table 23: SILworX - System Parameters for Digital Inputs, DI 8 LC: Channels Tab
