F3 DIO 8/8 01 3 Product Description
HI 800 179 E Rev. 2.00 Page 25 of 52
3.5.1 Product Data F3 DIO 8/8 014
The F3 DIO 8/8 014 model variant is intended for use in railway applications. The electronic
components are coated with a protective lacquer.
F3 DIO 8/8 014
Operating temperature -25…+70 °C (temperature class T1)
Output current DO+ Channels 1...3 and 5...7: 0.5 A at ≤ 70 °C
The output current of the channels 4 and 8 depends on the
ambient temperature.
Ambient temperature Output current
< 40 °C 2 A
40…60 °C 1 A
> 60 °C 0.5 A
Output current DO-
The output current of the channels 4 and 8 depends on the
ambient temperature.
Ambient temperature Output current
< 40 °C 2 A
40…60 °C 1 A
> 60 °C 0.5 A
Weight approx. 1 kg
Table 15: Product Data of F3 DIO 8/8 014
The remote I/O F3 DIO 8/8 014 meets the conditions for vibrations and shock test according to
IEC 61373, category 1, class B.
3.6 Certified HIMatrix F3 DIO 8/8 01
HIMatrix F3 DIO 8/8 01
CE EMC, ATEX Zone 2
TÜV IEC 61508 1-7:2000 up to SIL 3
IEC 61511:2004
EN ISO 13849-1:2008 up to Cat. 4 und PL e
UL Underwriters
Laboratories Inc.
ANSI/UL 508, NFPA 70 – Industrial Control Equipment
CSA C22.2 No.142
UL 1998 Software Programmable Components
NFPA 79 Electrical Standard for Industrial Machinery
IEC 61508
FM Approvals Class I, DIV 2, Groups A, B, C and D
Class 3600, 1998
Class 3611, 1999
Class 3810, 1989
Including Supplement #1, 1995
CSA C22.2 No. 142
CSA C22.2 No. 213
TÜV CENELEC Railway application
EN 50126: 1999 up to SIL 4
EN 50128: 2001 up to SIL 4
EN 50129: 2003 up to SIL 4
Table 16: Certificates
