3 Product Description X-AI 32 02
Page 16 of 60 HI 801 055 E Rev. 4.00
3.5 Product Data
General
Supply voltage 24 VDC, -15 %...+20 %, r
P
≤ 5 %, SELV, PELV
Current input min. 500 mA (without channels/transmitter supplies)
max. 1.5 A (in case of short-circuit of the transmitter
supplies)
Current input per channel min. 0 mA (without transmitter supply)
min. 30 mA (with transmitter supply)
Operating temperature 0...+60 °C
Storage temperature -40...+85 °C
Humidity max. 95 % relative humidity, non-condensing
Type of protection IP20
Dimensions (H x W x D) in mm 310 x 29.2 x 230
Weight approx. 1.4 kg
Table 7: Product Data
Figure 4: Views
