X-AI 32 02 3 Product Description
HI 801 055 E Rev. 4.00 Page 25 of 60
3.6.7 Connector Board Redundancy using Two System Base Plates
I/O Module Plug
Connection to the Field Zone (Cable
Plug in Row 1)
Connection to the Field Zone (Cable
Plug in Row 32)
Coding for Cable Plugs
Figure 8: Connector Board with Cable Plug, Variant X-CB 008 05
