3 Product Description X-AI 32 02
Page 18 of 60 HI 801 055 E Rev. 4.00
3.6 Connector Boards
A connector board connects the module to the field zone. Module and connector board
form together a functional unit. Insert the connector board into the appropriate slot prior to
mounting the module.
The following connector boards are available for the module:
Connector board Description
X-CB 008 01 Connector board with screw terminals
X-CB 008 02 Redundant connector board with screw terminals
X-CB 008 03 Connector board with cable plug
X-CB 008 04 Redundant connector board with cable plug
X-CB 008 05
Redundant connector board with cable plug, redundant field
termination assembly
X-CB 008 06 Three-fold redundant connector board with screw terminals
X-CB 008 07 Three-fold redundant connector board with cable plug
Table 10: Available Connector Boards
For high precision measurements, the following connector boards must be used:
Connector board Description
X-CB 019 01 Connector board with screw terminals
X-CB 019 02 Redundant connector board with screw terminals
X-CB 019 03 Connector board with cable plug
X-CB 019 04 Redundant connector board with cable plug
Table 11: Connector Boards for High Precision Measurements
3.6.1 Mechanical Coding of Connector Boards
I/O modules and connector boards are mechanically coded starting from hardware revision
AS10 to prevent them from being equipped with improper I/O modules. Coding avoids
incorrect installation of improper I/O modules thus preventing negative effects on redundant
modules and field zone. A part from that, improper equipment has no effect on the HIMax
system since only I/O modules that are correctly configured in SILworX enter the RUN
state.
I/O modules and the corresponding connector boards have a mechanical coding in form of
wedges. The coding wedges in the female connector of the connector board match with the
male connector recesses of the I/O module plug, see
Figure 5.
Coded I/O modules can only be plugged in to the corresponding connector boards.
