Himoinsa CEM7 User Manual

(APPENDIX II) CONTROL UNIT SCREENS | PAGE 79
* * * * * M o n d a y * * * * *

B L O Q [ 0 ] 1 0 : 0 0 . 1 1 : 0 0
A R R F [ 2 ] 1 5 : 5 0 . 1 7 : 0 0

T E S T [ 1 ] 2 0 : 0 0 . 2 2 : 0 0
Fig.1
Action type.
* * * * * M o n d a y * * * * *

B L O Q [ 0 ] 1 0 : 0 0 . 1 1 : 0 0
A R R F [ 2 ] 1 5 : 5 0 . 1 7 : 0 0

T E S T [ 1 ] 2 0 : 0 0 . 2 2 : 0 0
Fig.2
Periodicity.
* * * * * M o n d a y * * * * *

B L O Q [ 0 ] 1 0 : 0 0 . 1 1 : 0 0
A R R F [ 2 ] 1 5 : 5 0 . 1 7 : 0 0

T E S T [ 1 ] 2 0 : 0 0 . 2 2 : 0 0
Fig.3
Start time.
* * * * * M o n d a y * * * * *

B L O Q [ 0 ] 1 0 : 0 0 . 1 1 : 0 0
A R R F [ 2 ] 1 5 : 5 0 . 1 7 : 0 0

T E S T [ 1 ] 2 0 : 0 0 . 2 2 : 0 0
Fig.4
End time.
* * * * * SCHEDULES * * * * *

Thursday

Friday

Saturday
* * * * * SCHEDULES * * * * *

Sunday

Possible actions that can be scheduled are (in order of priority):
• Lock (BLOQ): prevents the genset from starting and inhibits the
activation of the counter.
• Forced start (ARRF): starts the genset and activates the contactor.
• Test (TEST): starts the genset without activating the contactor; in the
event of receiving an external start command.
• Free (----): no action is scheduled for that range; the start time and end
time have no effect.
The CEA7 control unit allows up to 5 different actions to be programmed on the
same day of the week. For each option is activation range is dened indicating
the hour and minute of the start and end; the start time must always be before
the end. The start time and end time are between 00:00 and 23:59.
From version CEx7 rev4.71 the frequency of the event can be programmed:
• Weekly (option [0]). Every week the scheduled event is carried out.
• Monthly (option [1]). Only during the rst week of the month (days 1-7
inclusive) is the scheduled event carried out.
• Bimonthly (option [2]). Only during the rst week (days 1-7 inclusive)
and third week of the month (days 15 to 21 inclusive) is the scheduled
event carried out.
Select day of the week and press  to program: action, frequency, start time,
start minute, end hour, end minute. To select programming 2-3-4-5 use cursors
▲▼and repeat the above process.
