(APPENDIX II) CONTROL UNIT SCREENS | PAGE 83
10.3.3 CUSTOMISING THE MANUFACTURER'S SCREEN
From the programming texts option of the control unit it is possible to customise
the manufacturer's screen.
H I M O I N S A
3 0 7 3 0 S A N J A V I E R
M U R C I A ( S p a i n )
T l f . + 3 4 9 6 8 1 9 1 1 2 8
10.3.4 PROGRAMMING SENSOR CURVES
From the parameters option, two response curves can be programmed applicable
to the temperature and pressure sensors. Response curves can also be
programmed for the main tank gauge and for an auxiliary tank connected to the
auxiliary analogue input (Anc).
* * * * * * SENSORS * * * * * *
1 . Temperature
2 . Pressure
3 . Fuel
* * * * TEMPERATURE * * * * *
P . 1 Ω 7 4 0 T M 3 0
P . 2 Ω 3 2 2 T M 5 0
P . 3 Ω 1 5 5 T M 7 0
Programming the response curves of the sensors is carried out by entering
decreasing resistance value points. For curve 1 associated with temperature
sensors, positive and negative values temperature are permitted; for curve 2
associated with pressure sensors only positive pressure values are permitted.
The maximum number of points is 8 per programmable curve.
With the cursor keys ▲▼each new point is selected and the resistance value is
entered, the range of value being limited between 0 and the resistance value of
the previous point. After entering the resistance value, the accept key is pressed
and the value associated with said resistance is entered.
* * * * MEASUREMENTS * * * *
P 0 1 . . . . . . . . . . . 4
P 0 2 . . . . . . . . . . . 5
P 0 3 . . . . . . . . . . . 0
Fig.2
No. of parameters
* * * * MEASUREMENTS * * * *
P 0 1 . . . . . . . . . . . 4
P 0 2 . . . . . . . . . . . 5
P 0 3 . . . . . . . . . . . 0
Fig.3
Value
10.3.1 TEXTS
We can associate a text to the programmable inputs, maximum 15 characters.
The control unit has an alphabet A-Z and numbers 0-9.
* * * * TEXTS * * * *
1 . PROGRAMMABLE 1
2 . PROGRAMMABLE 2
3 . PROGRAMMABLE 3
* * * * TEXTS * * * *
4 . SCREEN
10.3.2 CUSTOMISING THE PROGRAMMABLE ALARMS TEXT
From the programming texts option of the control unit it is possible to customise
the texts associated with the programmable alarms.
