Chapter 4 Battery Replacement
――――――――――――――――――――――――
CAUTION
Do not fix the back casing screws too tightly.
The torque about 0.5N ･ m is recommended.
Chapter 4
Battery
Replacement
1. Remove the two fastening screws of the rear cover,
using a Phillips screwdriver.
2. Remove the rear cover.
3. Remove the old battery without pulling the codes of
the snap.
4. Securely connect the battery to the battery snap.
5. Replace the rear cover and tighten the fastening
screws.
