Chapter 2 Measurement Procedure
――――――――――――――――――――――――
NOTE
2.4.3 Out
p
ut Function For Fre
q
uenc
y
･ At the 100 Hz and 1000 Hz ranges, ---- appears on
the counter when the frequency is lower than 10 Hz.
･ ---- appears on the counter, if the frequency is lower
than 1 Hz.
･ O. L. appears on the counter, if the frequency is
higher than 1 kHz.
･ If an input value is significantly lower than the
range, on accurate measurement may not be
achieved, resulting in ----, O. L. or display
fluctuations.
･ The 10 Hz range or 100 Hz range will display up to
125% of each range, however, only the range from
10% to 100% can be displayed with guaranteed
accuracy.
･ The frequencies, whose waveforms are special such
as inverters, would not be measurable, when the
carrier frequencies are lower than several kHz.
･ Full-wave rectification indicates twice the actual
value, due to an AC coupling in the internal circuit.
･ It would take time to stabilize the counter,
depending on the frequency range or the input
frequency.
Frequency measurement output is available only in
current modes.
An output of DC 1 V is produced for 1000-count on
the full scale of the frequency range. An output is
produced twice per second, the same as display
refreshing. (The output waveform will be in step
form for a large frequency change, due to D/A
outputs.)
1. To make settings, refer to the frequency
measurement procedure in a current mode.
2. Press
OUTPUT
.
REC
annunciator lights and
activates the output function.
